Multi-hole Shaving Die Materials
|
Die Type |
Multi-hole Shaving Dies |
Single-hole Shaving Dies |
|
Feature |
Multi-hole Shaving Dies |
Single-hole Shaving Dies |
|
Number of working holes |
Multiple |
One |
|
Wire processing |
Multiple wires simultaneously |
One wire at a time |
|
Production capacity |
Higher for multi-wire lines |
Suitable for single-wire processing |
|
Customization |
Hole number and arrangement |
Individual hole design |
|
Typical use |
Multi-wire production |
Single-wire production |
A multi-hole shaving die contains several precision shaving holes arranged within one die body.
During operation, individual wires pass through the holes while the cutting edges remove a controlled layer from the wire surface. The process can correct surface irregularities, remove scale or coatings, and achieve a more controlled final diameter.
Typical applications include:
- Copper wire
- Aluminum wire
- Steel wire
- Stainless steel wire
- Specialty metal wire
Key Features
Multiple Shaving Holes
Several working holes allow multiple wires to be processed at the same time, depending on the machine configuration.
Controlled Material Removal
Each hole is designed according to the incoming wire diameter, required shaving amount and finished diameter.
Precision Hole Geometry
The hole diameter, cutting edge and working section directly affect the final wire size and surface condition.
Custom Hole Arrangements
The number and arrangement of holes can be customized according to production requirements and equipment design.
How to Select Multi-hole Shaving Dies
For a suitable die design, provide:
Wire material
Incoming wire diameter
Finished wire diameter
Shaving allowance
Number of wires processed simultaneously
Required hole arrangement
Drawing/shaving machine model
Production speed
The die geometry should be matched to the actual wire and machine conditions rather than selected only by nominal hole diameter.
Applications
Multi-hole shaving dies can be used in:
- Wire surface finishing
- Precision wire sizing
- Copper wire processing
- Aluminum wire processing
- Steel wire processing
- Stainless steel wire processing
- Multi-wire production lines
- Specialty wire manufacturing
FAQ
Q: What is a Multi-hole Shaving Die?
A: It is a precision die containing multiple shaving holes for simultaneously removing a controlled amount of material from multiple wires.
Q: What materials can be processed?
A: Depending on the die material and design, multi-hole shaving dies can be used for copper, aluminum, steel, stainless steel and other metal wires.
Q: Can the number of holes be customized?
A: Yes. Hole quantity, hole arrangement, diameter and working geometry can be customized according to the production line.
Q: What information is needed for a quotation?
A: Provide the wire material, incoming and finished diameters, shaving allowance, number of wires, machine model and production speed.
